Desktop Cup Sealing Machine Fully Automatic Space Saving Customized Sealing Diameter

LD802 new desktop fully automatic sealing machine

Product Overview

This machine is a new desktop fully automatic sealing machine developed according to market demand. It can be customized for cups, bowls, boxes, bottles, barrels and jars in various shapes. The minimum order is one unit. It is economical and has beautiful effects, helping customers save costs. The sealing film is a plastic composite material. It can be a roll film or a sheet film, and you can choose either one. The roll film can be automatically punched, sealed and waste discharged, which solves the problem of sealing some cups and bottles without lids. No matter what shape, it can be sealed, saving space. It can seal one box, two boxes or four boxes at a time, which improves production efficiency and is very popular among users.

Machine functions and configuration:

1. One out of Six

2. Production speed: Six out of one: 1000-1200 boxes/hour

3. Production process: manual box placement, automatic box entry, air pressure sealing, automatic waste discharge, automatic box top.

4. Program control, stable and reliable.

5. The human-machine interface is touch screen control, simple operation, and the machine operation status can be monitored at any time.

6. Classic digital display temperature control meter, temperature difference of plus or minus 5 degrees, good sealing effect.

7. Precision guide rail, smooth walking, accurate positioning.

8. Taiwan photoelectric eye tracking, electrical integration.

9. Sealing diameter: 30-250mm can be customized

10. Sealing material: plastic composite film, aluminum foil composite film, PP, PVC, PE, PET, PS are all OK.

11. The size of the sealing film is 2-3mm larger than the cup mouth, the sealing is tight, and the appearance is beautiful.

12. Air pressure range: 4-8KG/CM2

13. Temperature range: 0-300 degrees

14. Power: 1000-2000W

15. Voltage: 220V

16. Machine appearance: stainless steel

17. Net weight: 100kg (this is a custom-made model, the weight will be slightly different)

18. Packing size: length 156*width 101*height 85cm

19. Packing method: wooden box

20. Accessories: one instruction manual, one hexagonal wrench, one cross screwdriver, one paper tube.

Precautions for Use:

1. Before using this machine, a grounding wire must be connected.

2. Pay attention to safety. Do not insert your hand into the machine when it is in the standby or power-on state.

3. In case of emergency, press the red emergency stop button directly.

4. When installing the sealing film, make sure to turn off the power.

5. If it is the first time to seal, the temperature should be increased gradually from low to high.

6. When placing the machine, make sure the four feet are level first and the ground surface is solid.

7. Regularly add grease to the guide columns to reduce wear on parts.

8. Clean up the hygiene every day, especially on the conveyor belt and the motor.

9. If there is a malfunction, non-professionals are not allowed to open the electrical box. Contact our after-sales service promptly.

Main configuration of the machine:

Payment Method:

After the contract is signed, 50% of the total contract amount will be paid as a deposit. The remaining 50% can be paid after the equipment is completed and can be inspected on-site or confirmed by video. After the equipment is inspected and qualified, the payment will be released and the equipment will be delivered.

Delivery Period:

7-10 days

Warranty Policy:

The machine is guaranteed for one year and provides lifetime service.
