Ready Soup Modified Atmosphere Packaging Machine

Product Overview

This machine is a disc rotary modified atmosphere fresh-keeping sealing machine developed according to customer requirements. It can inject fresh-keeping gases in different proportions to extend the shelf life of food in a refrigerated environment. The sealing film is a roll film, which is automatically hot-pressed and sealed, and can automatically top the cup/box. It can seal 2 boxes, 4 boxes or more boxes at a time, saving human resources and improving production efficiency.

Sealing machine functions and configurations:

1. One-out-one The mold can be replaced and is compatible with cups, bowls, boxes, bottles, barrels and cans of various shapes and sizes.

2. Production speed: One-out-one: 500-600 boxes/hour Production process: manual box placement, automatic injection of fresh-keeping gas in proportion, automatic film rolling and sealing, automatic printing of production date (this is optional), and automatic production of finished products.

3. Can be connected to the production line, unmanned operation, saving manpower and improving production efficiency.

4. Taiwan PLC program control, stable and reliable, the human-machine interface is a touch screen.

5. Classic digital display temperature control meter, temperature difference of plus or minus 5 degrees, good sealing effect.

6. Equipped with fault alarm and temperature alarm functions to ensure the sealing effect.

7. Taiwan photoelectric eye tracking, electrical integration.

8. Sealing material: consistent with the cup material, can be heated and bonded, plastic composite film or aluminum foil composite film, such as composite PP, composite PE, composite PET, composite PS, etc.

9. Air pressure range: 4-8KG/CM2

10. Adjustable temperature range: room temperature - 300 degrees

11. Power: 1000-2000W

12. Voltage: 110V or other voltages can be customized according to customer needs

13. Machine size: 1000*1000*1500MM (customized products, subject to actual conditions)

14. Machine frame structure: Made of high-quality stainless steel 304#, food-grade process 2B plate with brushed effect, dust-proof and rust-proof, acid-resistant and alkali-resistant; pure hand-polished and polished, fine workmanship.

15. Sealing system: constant temperature, intelligent temperature control, hot press sealing, sealing head is high-quality aluminum alloy, mold part: acid-resistant aluminum alloy mold (6061 aluminum alloy), CNC processing, high precision, anodized anti-oxidation treatment, no deformation, corrosion resistance, high hardness, long life. Non-sand cast aluminum!

16. Cup dispensing system: electric eye induction, base cylinder lifts up; upper cylinder connects to the pull-out mechanism to pull out.

17. Net weight: 500KG

18. Packing method: wooden box or wooden frame

19. Accessories: 2 10A fuses, one instruction manual, one hexagonal wrench, one cross screwdriver, one paper tube.

Main configuration list:

Operation screen: Taiwan Weiluntong touch screen human-machine interface

PLC: Delta PLC

Frequency Converter: Delta

Motor: Taili motor

Divider: Lianrui divider

Cylinder: Taiwan Yadeke cylinder

Solid state: Taiwan Yangming

Power supply: Delta

Relay: France Schneider

Mold assembly: Aluminum alloy oxidation

Disc assembly: Aluminum alloy oxidation

Payment Method:

After the contract is signed, 50% of the total contract amount will be paid as a deposit. The remaining 50% can be paid after the equipment is completed and can be inspected on-site or confirmed by video. After the equipment is inspected and qualified, the payment will be released and the equipment will be delivered.

Delivery Period:

10-15 days

Warranty Policy:

The machine is guaranteed for one year and provides lifetime service.
