Accurate Modified Atmosphere Packaging Machine Saving Manpower 1000-2000W

LD642 vertical extended version sealing machine

One out of four

Product Overview:

This machine is a vertical extended version sealing machine developed according to customer requirements, which solves the sealing problem of cups, bowls, boxes, bottles, barrels and cans with super large diameters and specifications. The machine is more stable, the sealing is more accurate, and the mold replacement is more convenient. The appearance of the machine is tall and noble, the body is made of high-quality stainless steel, the vertical structure is seamless from top to bottom, it takes up little space and is highly efficient. The sealing film is a roll film or a sheet film, one of the two can be selected, automatic hot pressing sealing, automatic ejection, saving manpower. For large-sized containers, multiple boxes can be sealed at one time, saving the company effort and money, greatly improving production efficiency, and is very popular among users.

Features:

This sealing machine can have multiple molds, and mold change is easy.

High efficiency, small footprint, and inexpensive.

Vertical machine, easy to move and store.

Stable structure, more precise sealing.

Specially designed for large sizes or large sizes with multiple semi-automatic machines;

Short delivery time, fine workmanship, custom-made.

Use the most sophisticated technology to get you the most beautiful heart.

Use the highest cost to get you the least investment.

Machine functions and configuration:

1. One out of four

2. Production speed: One out of four: 500-600 boxes/hour (the actual speed is related to the operator's operating proficiency and the container and material)

3. Production process: manual box placement, automatic box feeding (referring to the bottom mold), air pressure sealing, automatic waste discharge, automatic top box.

4. Specially designed for sealing large-sized or large-sized containers with multiple outputs.

5. Seven-inch true color human-machine interface, program control, stable and reliable.

6. The human-machine interface is controlled by a digital 32-bit true color screen, which is easy to operate and monitors the machine's operating status at any time.

7. Classic digital temperature control meter, temperature difference of plus or minus 5 degrees, good sealing effect.

8. The frame adopts a vertical structure, which is integrated from top to bottom, and has brake casters underneath, which can be moved anywhere at any time.

9. There are safety shields before and after the sealing station, which is safe and beautiful.

10. Precision guide rails, smooth walking and accurate positioning.

11. Taiwan photoelectric eye tracking, electrical integration.

12. Sealing materials: plastic composite film, aluminum foil composite film, PP, PE, PET, PS are all OK.

13. The size of the sealing film is 2-3mm larger than the edge of the container (referring to the roll film sealing), and the handle position can be designed, the sealing is tight and the appearance is beautiful.

14. Air pressure range: 4-8KG/CM2

15. Temperature range: 0-300 degrees

16. Power: 1000-2000W

17. Voltage: 220V 50HZ

18. Machine size: 1200*1080*1450mm (customized machine is subject to actual size)

19. Machine appearance: stainless steel and aluminum profile

20. Net weight: 200KG

21. Packing method: wooden box

22. Accessories: 2 10A fuses, an instruction manual, an Allen wrench, a Phillips screwdriver, and a paper tube.

Main configuration list:

Operation screen: 7-inch touch screen

Motor: Taili

Cylinder: Taiwan AirTac

Switch power supply: Delta

Mold assembly: aluminum alloy

Solenoid valve: Taiwan AirTac

Temperature control meter: Ruiyuan

Photoelectric: Taiwan Yangming

Leakage switch: France Schneider

Relay: France Schneider

Oil-water separator: Xingchen

Precautions for Use:

1. Before using this machine, a grounding wire must be connected.

2. Pay attention to safety. Do not insert your hand into the machine when it is in the standby or power-on state.

3. In case of emergency, press the red emergency stop button directly.

4. When installing the sealing film, make sure to turn off the power.

5. If it is the first time to seal, the temperature should be increased gradually from low to high.

6. When placing the machine, make sure the four feet are level first and the ground surface is solid.

7. Regularly add grease to the guide columns to reduce wear on parts.

8. Clean up the hygiene every day, especially on the conveyor belt and the motor.

9. If there is a malfunction, non-professionals are not allowed to open the electrical box. Contact our after-sales service promptly.

Payment Term:

50% Advanced payment.

When the equipment finished, use the customer’s product take a video ,after the confirmation, Received the balance payment, arrange the delivery.

Delivery Time:

10-15 Days

Warranty policy:

The whole machine is under warranty for one year and has lifetime service.
