Plastic Box Packed Fresh Fish Meat  Modified Atmosphere Packaging Machine

Product Overview

Introducing the Plastic Bos Packed Fresh Fish Meat Modified Atmosphere Packaging Machine, designed for optimal freshness and quality preservation. This cutting-edge technology utilizes modified atmosphere packaging (MAP) to ensure that your fish products stay fresh and flavorful for extended periods. The innovative design not only enhances shelf life but also maintains the aesthetic appeal of the packed fish.

Key Features:
- Superior freshness retention
- User-friendly interface
- Energy-efficient operation
- Compact design suitable for various production environments

Perfect for seafood processors and distributors, the Plastic Bos Packed Fresh Fish Meat Modified Atmosphere Packaging Machine is your go-to solution for meeting market demands while ensuring that quality is never compromised.

Machine functions and configuration:

1. One out of four

2. Production speed: one out of four: 1200-1500 pieces/hour

3. Workflow: automatic boxing, injection of fresh-keeping gas, automatic hot pressing and sealing, automatic date printing, automatic finished product output.

4. The appearance of the machine is simple and elegant, using high-quality stainless steel 304, food-grade industrial 2B plate with brushed effect, dust-proof and rust-proof, acid-resistant and alkali-resistant.

5. Purely hand-polished and polished, fine workmanship, small chassis interface, no sharp corners, conscientious quality.

6. All parts are added by CNC machine, which is accurate, standard and high-precision, so that the whole machine can run smoothly for a long time and has a long life.

7. The chain is food-grade stainless steel 304, acid-resistant and alkali-resistant, can be directly washed with water, durable and not easy to deform.

8. Frame structure: It is welded with thick steel structure, cooled and formed for one month, and then plane-planed by gantry milling machine, solid and stable.

9. Sealing mold structure, stainless steel + alumina, durable, no rust, fast heat conduction.

10. Servo motor drive, classic digital temperature controller, temperature balance, plus or minus 1 degree, reliable sealing, no water leakage, good surface flatness.

11. Taiwan photoelectric eye tracking to ensure that the sealing pattern is aligned and centered.

12. Delta PLC program control, Taiwan human-machine interface, fault alarm, easy to check faults.

13. Sealing material: As long as the material matches the box, it can be used, such as: plastic composite heat-sealing film or aluminum foil composite film, the film thickness is not less than 0.1MM.

14. Air pressure range: 4-8KG/CM2

15. Temperature range: 0-250 degrees

16. Power: 5000-8000W

17. Voltage: 380V 50HZ

18. Machine size: Customized model is subject to the final plan

19. Packing method: wooden box

List of electrical accessories:

Human-machine interface: Taiwan Weilun

PLC: Taiwan Delta

Solenoid valve: Taiwan AirTac

Air switch: France Schneider

Master cylinder: Taiwan AirTac

Switch power supply: Taiwan Delta

Temperature control solid state: South Korea

Drive motor: Taiwan servo

Temperature control meter: Japan Fuji

Repeater: France Schneider

Circuit breaker: France Schneider

Frequency converter: Taiwan Delta

Host structure: Stainless steel 304 frame full thickness 3.0

Sealing mold: Six series aluminum, 6061 aluminum alloy, non-casting acidified aluminum

Sealing hot plate: aluminum plate

After-sales Service:

We provide one-year free warranty and lifetime service. During the warranty period, free on-site service can be provided twice a year. If multiple on-site visits are required, the cost of accommodation, meals and transportation for the round trip shall be borne by the buyer.

Payment Method:

After the contract is signed, 50% of the total contract amount will be paid as a deposit. The remaining 50% can be paid after the equipment is completed and can be inspected on-site or confirmed by video. After the equipment is inspected and qualified, the payment will be released and the equipment will be delivered.

Delivery Period:

20-25 days

Warranty Policy:

The machine is guaranteed for one year and provides lifetime service.
