Sealerall Cupping Filling Sealing Capping Machine for paste

This machine is a fully automatic disc filling and sealing machine developed according to customer requirements. The front end can be equipped with a bottle sorter or bottle washing machine, and the back end can be equipped with a capping machine and labeling machine and other production lines. It is unmanned, saving manpower and improving production efficiency. The sealing film can be a roll film or a sheet film, and one of the two can be selected. It automatically drops the cup, automatically heats and seals, leaves a coding signal, and automatically transports the cup out, saving manpower. It can seal four or more cups at a time, and the quantity can be selected according to demand, greatly improving production efficiency.

Introduction to the functions and configuration of the sealing machine:

1. One out of two

2. Production speed: One out of two: 1000-1200 cups/hour Workflow: automatic cup dropping, automatic filling of materials, with storage hopper, automatic refilling when there is no material in the hopper (this is optional), automatic hot pressing sealing, automatic cup discharge.

3. Filling accuracy: plus or minus one percent

4. Filling material range: liquid, emulsion, paste.

5. Filling method: stainless steel 316 servo pump.

6. Can be connected to the production line, the front end can be equipped with a bottle unscrambler or bottle washer, and the back end can be equipped with a capping machine and labeling machine and other production lines, unmanned operation, saving manpower and improving production efficiency.

7. Delta PLC program control, stable and reliable, the human-machine interface is a touch screen, which is convenient for adjusting parameters and fault alarms.

8. Adjustable temperature range: room temperature -300 degrees, classic digital display temperature control meter, temperature difference plus or minus 5 degrees, good sealing effect.

9. Equipped with fault alarm and temperature alarm functions to ensure the sealing effect.

10. Taiwan photoelectric eye tracking, electrical integration.

11. Sealing material: As long as it matches the bottle material, plastic composite film or aluminum foil composite film that can be heated and bonded can be used, such as composite PP, composite PE, composite PET, composite PS, etc.

12. Air pressure range: 4-8KG/CM2

13. Power: 1000-2000W

14. Voltage: 220V, 110V or other voltages can be customized according to customer needs

15. Machine appearance: stainless steel 304

16. Net weight: 500KG (this is a reference value, customized products, subject to actual conditions)

17. Packing method: wooden frame

18. Accessories: a tool box, a manual, a hexagonal wrench, and a cross screwdriver.

After-sales service:

One-year warranty, lifelong service.

During the warranty period:

If there are quality problems with accessories, the accessories fee can be waived and the shipping fee shall be borne by the buyer.

Main configuration list:

Operation screen: Taiwan Weilun touch screen

PLC: Delta

Frequency Converter: Delta inverter

Motor: Taili motor

Divider: Lianrui divider

Cylinder: Taiwan Yadeke cylinder

Solid state: Taiwan Yangming

Power supply: Delta

Relay: France Schneider

Mold assembly: Aluminum alloy oxidized rust-proof treatment

Disc assembly: Aluminum alloy oxidized rust-proof treatment or polymer plastic (select according to the actual situation of the bottle provided by the customer)

Precautions for Use:

1. Before using this machine, a grounding wire must be connected.

2. Pay attention to safety. Do not insert your hand into the machine when it is in the standby or power-on state.

3. In case of emergency, press the red emergency stop button directly.

4. When installing the sealing film, make sure to turn off the power.

5. If it is the first time to seal, the temperature should be increased gradually from low to high.

6. When placing the machine, make sure the four feet are level first and the ground surface is solid.

7. Regularly add grease to the guide columns to reduce wear on parts.

8. Clean up the hygiene every day, especially on the conveyor belt and the motor.

9. If there is a malfunction, non-professionals are not allowed to open the electrical box. Contact our after-sales service promptly.
